LJMJ-500PS Digital Display Corner Key Cutting Saw
Introduction
LJMJ-500PS digital display corner key cutting saw is a corner-key cutting machine equipped with digital display system. It is often used for aluminum corner connector cutting into right pieces, aluminum and curtain wall profile cutting, and plastic profile cutting. With Micro PC CNC control system, man-machine interface operation, and touch screen input and control, it is convenient for the corner key cutting saw to set the data. Lantoky has been engaged in producing corner-key cutting machines for over ten years. Our products are exported to many countries and regions, such as North America, East Europe and the Middle East.
Features
1. LJMJ-500PS digital display corner key cutting saw is suitable for large volume production.
2. It adopts the imported carbide saw blade that ensures accurate processing and high endurance.
3. This corner-key cutting machine is equipped with automatic profile feeding device.
4. Linear motion bearing produces less resistance force and ensures high processing accuracy.
5. Lantoky corner key cutting saw possesses features of high automation, reliability and high production efficiency.
6. Clamping and feeding process adopt pneumatic control.
7. Our digital display corner-key cutting machines adopt automatic counters.
Parameters Data
Model | LJMJ-500PS |
Type | Digital Display Corner Key Cutting Saw |
Cutting Sag | 0.1 mm |
Cutting Plainness | 0.1 mm |
Cutting Harshness | Ra12.5 µ m |
Power Supply | 380V 50 Hz (Three Phase, Four Wire) |
Saw Blade Diameter | Φ500 mm |
Rotary Speed | 2800 r/min |
Feeding Speed | 0 to 3 m/min |
Feeding Profile Length | 0 to 600 mm |
Air Pressure | 0.5 to 0.8 Mpa |
Air Consumption | 200 L/min |
Weight of Corner-Key Cutting Machine | 800 kg |
Lantoky® Machine is a professional manufacturer of digital display corner key cutting saws in China. We also provide insulating glass machine, PVC window and door machine and curtain wall equipment for sale. Our products are well appreciated for their advanced design, sophisticated manufacturing, excellent quality and full service. Lantoky corner-key cutting machines or corner key cutting saws are highly appraised by customers from over 100 countries and districts.
