MS90 Mullion Cutting Saw
Introduction
MS90 mullion saw is mainly used for cutting PVC mullion profiles with wedge shape of both ends. The machine body is welded by high quality steel. Our mullion cutting saws or mullion cutting machines have passed aging treatment, which ensures high intensity and rigidity. They also adopt hard alloy saw blade with high cutting speed, high production efficiency and high processing precision. This type of mullion saw can complete two V shape cutting at one time. As a professional manufacturer and supplier of mullion cutting saws in China, Lantoky is able to provide customers with high-quality mullion cutting machine for PVC profiles.
Features
1. MS90 mullion saw adopts horizontal and compact structure for high cutting precision.
2. Lantoky mullion cutting saw features small volume, easy operation and long service life.
3. It is generally matched with V notch cutting machine to use.
4. Our mullion cutting machines are simple and convenient to operate and maintain.
Specifications of MS90 Mullion Saw
Model | MS90 Mullion Cutting Saw |
Working Air Pressure | 0.5 to 0.8 Mpa |
Air Consumption | 15 L/min |
Power Supply | 380V 50 Hz |
Input Power of Mullion Saw | 2.2 kW |
Saw Blade Rotary | 2800 r/min |
Cutting Length | 450 mm to 3500 mm |
Cutting Height | 90 mm |
Cutting Width | 120 mm |
Dimension | 7500 mm × 1720 mm × 1390 mm |
Weight of Mullion Cutting Saw | 300 kg |
Service
1. Lantoky provides one year guarantee time. During the warranty period, we supply free repair for mullion saws. But for some wearing parts, such as milling cutter, saw blade, electromagnetic valve, belt and chain, the express fee should be paid by the buyer.
2. We try our best to deal with any question about our mullion cutting saws.
3. If our customers need our company to send engineers to test mullion saws and to train their workers, they should pay for our engineers' round trip tickets, board and lodging during testing and teaching, and subsidy USD 40 per day.
Delivery Time
1. For domestic customers, we will deliver our mullion cutting saws within 15 to 20 days after receiving customers' order.
2. For oversea clients, Lantoky will deliver mullion saws within 25 to 30 days after receiving their order.
Lantoky® Machine is a leading supplier and exporter of door and window equipment in China. We mainly provide mullion cutting saw, insulating glass machine, curtain wall equipment, and so on. Complying with European standards, we always purchase main parts internationally. Our mullion saws have passed CE and UL certifications. They are exported to many countries and regions, such as North America, East Europe and the Middle East.
