HSC-F5 CNC Corner Cleaning Machine
Description
HSC-F5 CNC corner cleaning machine is the special equipment for 90° cleaning welding slag of PVC door and window. It can clean the outside corner, inner corner, top and bottom surfaces at one time. As a part of welding and cleaning processing line, this PVC corner cleaning machinery has become an ideal choice for many large and medium-sized UPVC window and door factories. Parker CNC corner cleaning machine is equipped with touch screen, LED display screen and professional cleaning software, which makes it convenient to work and monitor all cleaning process.
Characteristics
1. Main parts of this PVC corner cleaning machinery are imported originally, ensuring reliable operation.
2. HSC-F5 CNC corner cleaning machine has problem protection system and alarm device.
3. The touching screen can show users the working situation, which can help operators easily test problems.
4. This high-speed PVC corner cleaning machinery protects itself when breaking down. It can display faults and resolve methods.
5. The feeding of this CNC corner cleaning machine adopts ball guide rail with high precision. It can reduce the feeding error and make the profile corner more beautiful.
Technical Specifications
| Model | HSC-F5 |
| Type | CNC PVC Corner Cleaning Machinery |
| Voltage | 220 V 50 Hz |
| Total Power | 1.5 kW |
| Air Pressure | 0.4 to 0.7 MPa |
| Air Consumption | 11 L/min |
| Profile Range (W × H) | 20 mm / 120 mm × 20 mm / 300 mm |
| Overall Dimension | 1650 mm × 1000 mm × 1500 mm |
| Weight of CNC Corner Cleaning Machine | 800 kg |
Service
1. Parker provides one year guarantee time. During the warranty period, we supply free repair for PVC corner cleaning machinery. But for some wearing parts, such as milling cutter, saw blade, electromagnetic valve, belt and chain, the express fee should be paid by the buyer.
2. We try our best to deal with any question about our CNC corner cleaning machines.
3. If our customers need our company to send engineers to test machines and to train their workers, they should pay for our engineers' round trip tickets, board and lodging during testing and teaching, and subsidy USD 40 per day.
Established in 2003, Parker Machinery Co., Ltd has developed an assembly line for door, window, curtain wall and insulating glass equipment. With ten years' production experience, Parker has become a leading manufacturer of PVC corner cleaning machinery. The operation of high precision, advancement and specialty ensure that we are able to supply high-quality CNC corner cleaning machines for customers. Our products are exported to many countries and regions, such as North America, East Europe and the Middle East. They have won widespread praise and recognition by customers.
